OMNIScanner User Guide

4 - 2

With the OMNI

Fiber

adapter attached, press the (Measurements)

function key to display the Fiber Tests screen for fiber optic cabling.

Highlight the test you want to perform using the é or ê keys on your

keypad and press ENTER, or direct-dial a test by pressing its associated

number on the OMNI

Scanner

keypad.

General Information

Most test result screens have a retest feature for diagnostic purposes.

Press (Retest) to run continuous tests for the same cable.

Press (Retest) once more to stop the continuous measurement.

OMNI

Scanner

will display the last measured data.

Tests that require the use of OMNI

Remote

will have small icons in the

upper right corner of the titlebar indicating whether the information on the

screen is pertinent for OMNI

Scanner

or OMNI

Remote
