6. To verify the software update, press and hold the Backlight key (located right

above the ESC key). The software version number will be displayed.

7. To verify the update, press OMNIScanner’s (Setup) function key, and

then select the option Remote Info. The new software version will be

displayed.

NOTE

Always update the OMNIScanner software together with the Scanlink

Tools software to ensure compatibility.

Com 1

or Com 2

DB-9 to DB-25

or DB-9 to DB-9

Serial Cable

AC Adapter

Test Cable

CHAPTER 10: Updating Scanner Software
