CHAPTER 3: Getting Started: Fiber Optic Networks

2. To change the number of Splices, use the down-arrow to highlight the field

and press ENTER. Use the up-arrow or down-arrow key to adjust the number

of splices in your link. To determine the total number of splices, simply count

all of the splices on one fiber. OMNIScanner will assume that both fibers of a

duplex link have the same amount of splices.

3. After editing the fields, press to run the Autotest.

OMNIScanner starts the Autotest after the number of connections and splices

has been entered.

NOTE

If you are running a Fiber Test Options for further information.)

4. Swap the Launch Cable’s connectors as indicated in the graphic. Do not

disconnect the Launch Cables from the OMNIFiber adapters!

5. Press to complete the Autotest.
